Description
SONAR AF
Aluminum Foil Edition
Mast Options: AF72 / AF85
Includes:
- AF72 or AF85 Mast
- AF Board Adaptor
- A700 Fuselage
- S270 Stabilizer with cover
- Tool Kit
- Sonar Board Adaptor Screw Pack A (M8x40)
- Sonar Fuselage Screw Pack B (M8x35 Screws, M8 Flat Washers)
- Sonar Stabilizer Screw Pack C (M8x16mm)*
- Sonar Travel Bag
- Front Wings Sold Separately**
- Foil to board mounting screws sold separately**
Start building your modular quiver here. The new refined aluminium mast profile section delivers an optimal balance between light weight and exceptional strength, so you can kite, wing, surf and tow foil with confidence, making use of the fully interchangeable Sonar Foil System to extend your playtime on the water. Engineered to last, with exceptional strength to weight ratio, and our unique GeoLock system for a clean, direct feel with minimum resistance on the water. The AF85 mast increases overall ride performance in choppy conditions. The AF72 mast is ideal for shallower waters, and prone surf foiling. Now with A700 Fuselage for added stability, and new S270 Carbon Stabilizer for performance and efficiency.
Features
- Modular Foil System
- Sonar AF72 or AF85 Mast
- GeoLock Load Bearing Connection
- New S270 Carbon Stabilizer with easy recovery from surface breaching
- Sonar AF Foil Board Adaptor
- Industry-standard 165x90mm bolt pattern
- NEW 700mm Fuselage
- Supplied with Sonar Travel Bag
- Front Wings Sold Separately
- Foil to board mounting screws sold separately
North Foil Hardware Guide
| Connection | Model | Head | Qty and Length | Diameter |
|---|---|---|---|---|
| Board Adaptor to Mast (A) | Recessed Star | 2 x 40mm | M8 | |
| Alloy Fuselage to Mast (B) | Star Socket | 2 x 35mm | M8 | |
| Carbon Fuselage to Mast (B2) | Recessed Star | 2 x 30mm | M8 | |
| Fuselage to Stabilizer (C) | Recessed Star | 2 x 16mm | M8 | |
| Front Wing to Fuselage (D-I) | MA v2 700 | Recessed Star | 3 x 23mm | M8 |
| Front Wing to Fuselage (D-I) | MA v2 850 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | MA v2 1050 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | MA v2 1200 | Recessed Star | 3 x 30mm | M8 |
| Front Wing to Fuselage (D-I) | MA v2 1500 | Recessed Star | 3 x 33mm | M8 |
| Front Wing to Fuselage (D-I) | MA v2 1850 | Recessed Star | 3 x 35mm | M8 |
| Front Wing to Fuselage (D-I) | MA v2 2100 | Recessed Star | 3 x 35mm | M8 |
| Front Wing to Fuselage (D-I) | MA v2 2400 | Recessed Star | 3 x 40mm | M8 |
| Front Wing to Fuselage (D-I) | SF 580 | Recessed Star | 3 x 23mm | M8 |
| Front Wing to Fuselage (D-I) | SF 680 | Recessed Star | 3 x 23mm | M8 |
| Front Wing to Fuselage (D-I) | SF 830 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | SF 930 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | SF 1080 | Recessed Star | 3 x 30mm | M8 |
| Front Wing to Fuselage (D-I) | SF 1230 | Recessed Star | 3 x 30mm | M8 |
| Front Wing to Fuselage (D-I) | HA 550 | Recessed Star | 3 x 23mm | M8 |
| Front Wing to Fuselage (D-I) | HA 650 | Recessed Star | 3 x 23mm | M8 |
| Front Wing to Fuselage (D-I) | HA 750 | Recessed Star | 3 x 23mm | M8 |
| Front Wing to Fuselage (D-I) | HA 850 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | HA 950 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | HA 1050 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | HA 1150 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | HA 1250 | Recessed Star | 3 x 30mm | M8 |
| Front Wing to Fuselage (D-I) | HA 1450 | Recessed Star | 3 x 30mm | M8 |
| Front Wing to Fuselage (D-I) | Pump 1800 | Recessed Star | 3 x 33mm | M8 |
| Front Wing to Fuselage (D-I) | Pump 2050 | Recessed Star | 3 x 33mm | M8 |
| Front Wing to Fuselage (D-I) | DW 750 | Recessed Star | 3 x 23mm | M8 |
| Front Wing to Fuselage (D-I) | DW 900 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | DW 1100 | Recessed Star | 3 x 25mm | M8 |
| Front Wing to Fuselage (D-I) | DW 1400 | Recessed Star | 3 x 30mm | M8 |
