Find Your Foil Hardware
Axis
S-Series
820, 920, 1020 only M8 x 25mm Star Recessed Screw
All other surf front wings M8 x 20mm Star Recessed Screw
Stabilizer M6 x 25mm Star Recessed Screw
Fuselage M8 x 70mm Star Recessed Screw
Mast plate M8 x 35mm Star Recessed Screw
Plate to board M8 x 25mm Star Recessed Screw
K-Series
Front wing M6 x 25mm Star Recessed Screw
M6 x 28mm Star Recessed Screw
M6 x 30mm Star Recessed Screw
Stabilizer M6 x 25mm Star Recessed Screw
Fuselage M8 x 70mm Star Recessed Screw
Mast plate M8 x 35mm Star Recessed Screw
Plate to board M8 x 25mm Star Recessed Screw
Black Series
Front wing M6 x 14mm Star Recessed Screw
M8 x 20mm Star Recessed Screw
Stabilizer M6 x 25mm Star Recessed Screw
Fuselage M8 x 70mm Star Recessed Screw
Mast plate M8 x 35mm Star Recessed Screw
Plate to board M8 x 25mm Star Recessed Screw
Other Stabilizers
500mm x 90mm M6 x 25mm Star Recessed Screw
440mm x 90mm M6 x 25mm Star Recessed Screw
400mm x 90mm M6 x 25mm Star Recessed Screw
460mm x 60mm M6 x 22mm Star Recessed Screw
400mm x 60mm M6 x 22mm Star Recessed Screw
420mm x 60mm M6 x 22mm Star Recessed Screw
380mm x 60mm M6 x 22mm Star Recessed Screw
390mm x 80mm M6 x 25mm Star Recessed Screw
370mm x 80mm M6 x 25mm Star Recessed Screw
340mm x 80mm M6 x 25mm Star Recessed Screw
500mm x 90mm Anhedral M6 x 25mm Star Recessed Screw
Cabrinha
Speed Front Wing M8 x 27mm Hex Recessed Screw
Lift Front Wing M8 x 27mm Hex Recessed Screw
Carve Front Wing M8 x 27mm Hex Recessed Screw
M8 x 40mm Hex Recessed Screw
M8 x 45mm Hex Recessed Screw
Varial S,M,L Front Wing M8 x 25mm Hex Recessed Screw
M8 x 35mm Hex Recessed Screw
M8 x 38mm Hex Recessed Screw
Speed, Lift Stabilizer M8 x 14mm Hex Recessed Screw
Carve, Varial Stabilizer M8 x 20mm Hex Recessed Screw
Mast (both ends) M8 x 40mm Hex Recessed Screw
Plate to board M8 x 25mm Hex Recessed Screw
F-One
Mast plate M6 x 25mm Hex Recessed Screw
Mast foot to mast M6 x 25mm Hex Recessed Screw
Split fuse to tail M6 x 25mm Hex Recessed Screw
Stabilizer M6 x 16mm Hex Recessed Screw
Carbon fuse to titan M6 x 32mm Hex Recessed Screw
Alu fuse to mast foot M6 x 25mm Hex Recessed Screw
Board M6 x 25mm Hex Recessed Screw
GoFoil
Plate to board bolts M8 x 30mm Phillips Recessed Screw
Lift
Fuselage M6 x 30mm Hex Recessed Screw
Board screws M8 x 30mm Hex Recessed Screw
Stabilizer M6 x 15mm Hex Recessed Screw
Liquid Force
Front wing M8 x 24mm Hex Recessed Screw
Stabilizer M8 x 16mm Hex Recessed Screw
Fuselage M8 x 40mm Hex Recessed Screw
Mast top M8 x 28mm Hex Recessed Screw
QR collar M8 x 16mm Hex Recessed Screw
Mast plate to board M8 x 25mm Hex Recessed Screw
MFC
Mast to board M8 x 30mm Hex Recessed Screw
Fuselage M6 x 30mm Hex Recessed Screw
Front wing M6 x 20mm Hex Recessed Screw
Stabilizer M6 x 20mm Hex Recessed Screw
Moses / SabFoil
Alu Mast to Plate M8 x 40mm Hex Recessed Screw
Alu Mast to Tuttle M8 x 40mm Hex Socket Screw
Alu Fuse M8 x 40mm Hex Socket Screw
Alu Plate to Board M8 x 30mm Hex Button Screw
710 Fuse M6 x 25mm Hex Socket Screw
647 Kite Fuse M6 x 20mm Hex Socket Screw
1100 M6 x 30mm Star Recessed Screw x 2
M6 x 35mm Star Recessed Screw x 1
873 M6 x 45mm Star Recessed Screw x 1
M6 x 50mm Star Recessed Screw x 2
790 M6 x 30mm Star Recessed Screw x 2
M6 x 35mm Star Recessed Screw x 1
633 M6 x 30mm Star Recessed Screw
683 M6 x 25mm Star Recessed Screw
679 M6 x 25mm Star Recessed Screw
695 M6 x 25mm Star Recessed Screw
720 Balz M6 x 25mm Star Recessed Screw
718 M6 x 25mm Star Recessed Screw
590 M6 x 20mm Star Recessed Screw x 2
M6 x 25mm Star Recessed Screw x 1
558 M6 x 20mm Star Recessed Screw x 2
M6 x 25mm Star Recessed Screw x 1
550 M6 x 20mm Star Recessed Screw
548 M6 x 20mm Star Recessed Screw
Havoc 645 M6 x 20mm Star Recessed Screw
637 M6 x 20mm Star Recessed Screw
670 M6 x 20mm Star Recessed Screw
483 M6 x 16mm Star Recessed Screw x 1
M6 x 20mm Star Recessed Screw x 1
450 M6 x 16mm Star Recessed Screw x 1
M6 x 21mm Star Recessed Screw x 1
421 M6 x 16mm Star Recessed Screw
420 M6 x 16mm Star Recessed Screw
330 M6 x 16mm Star Recessed Screw
325 M6 x 16mm Star Recessed Screw
Naish
Plate standard screws M6 x 25mm Star Recessed Screw
Plate Abra screws M6 x 30mm Star Recessed Screw
Mast (both ends) M6 x 30mm Star Recessed Screw
Wing and Stabilizer M6 x 20mm Star Recessed Screw
Neil Pryde
Plate board screws M8 x 28mm Star Recessed Screw
Plate to mast M8 x 35mm Star Recessed Screw x 1
M8 x 60mm Star Recessed Screw x 1
Tuttle to mast M8 x 35mm Star Recessed Screw x 1
M8 x 65mm Star Recessed Screw x 1
Tuttle to board M6 x 35mm Star Recessed Screw
Fuselage M8 x 60mm Star Recessed Screw
Front wing M8 x 32mm Star Recessed Screw
Stabilizer M8 x 18mm Star Recessed Screw
North
850 Front M8 x 25mm Star Recessed Screw
1150 Front M8 x 30mm Star Recessed Screw
1650 Front M8 x 30mm Star Recessed Screw
Stabilizer M8 x 16mm Star Recessed Screw
Fuselage M8 x 40mm Star Socket Screw
Mast Plate M8 x 40mm Star Recessed Screw
Board w/ tracks M8 x 30mm Star Recessed Screw
Board w/ inserts M8 x 23mm Star Recessed Screw
Slingshot
Plate board screws M8 x 25mm Recessed Screw
Plate to mast M8 x 40mm Hex Recessed Screw
Tuttle to mast M8 x 75mm Hex Socket Screw
Tuttle to board M10 x 45mm Hex Socket Screw
(A) Mast to fuse M8 x 45mm Hex Socket Screw
(B) Mast to fuse M8 x 50mm Hex Recessed Screw
(B) Front wing to cap M8 x 23mm Hex Recessed Screw
Front wing to fuse M6 x 25mm Hex Recessed Screw
Stabilizer M6 x 30mm Hex Recessed Screw
UniFoil
Board screws M8 x 30mm Hex Socket Screw
Fuselage M8 x 30mm Hex Recessed Screw
Stabilizer M6 x 15mm Hex Recessed Screw
